GYROZEN

Features

- Compact design built to accommodate PCR tubes, microtubes and cryotubes (0.2 to 2.0 ml)
- Soft touch control panel and trendy touch wheel is highly sensitive and intuitive to input parameters.
- 3.5" LCD window with simultaneous display of all operational parameters of set and actual figures
- Selectable time mode of "at set SPEED" for counting running time only when reached the set speed
- A separate "PULSE" key for quick spin
- Parameters can be changed during operation.
- Key lock function helps the set-parameters secured during operation.
- Lid drop protection design allows easiness and safety when loading or unloading sample.
- With motorized lid mechanics, only a gentle touch is sufficient to close and open the lid.
- Bio-seal (Public Health England Porton Down) certified Easy-lock rotor

Technical Specifications

Max. RPM: 15,000 rpm
Max. RCF: 21,583 x g
Max. capacity: 36 x 1.5/2.0 ml, 10 x 5.0 ml, 4 x 8-tube PCR strips
Time control: Pulse, timed < 100 min or continuous
Time counting range: Selectable, at set speed or from starting
Automatic RCF/ RPM conversion: Yes
Noise level (dependent on rotor): ≤60 dB
ACC/DEC ramps: 9 / 10
Acc. time to max. speed: ≤15
Dec. time from max. speed: ≤15
Program memory: 100
Parameters on display window: Simultaneous display of all parameters of set and actual figures
Display: 3.5" LCD
Imbalance cut-off: Yes
Safety lid lock: Yes
Lid drop protection: Yes
Motorized lid open & close: Yes
Automatic lid release at completion: Yes
Dimension (W x D x H, mm): 240 x 378 x 240
Power Requirement (VA): 450
Weight without rotor (kg): 11.9
Power supply: AC 220-230 V, 50/60 Hz (110V optional)
CE Mark: Yes
Cat. No.: GZ-1536 (GZ-1536-110)
