1848R
Features Technical Specifications Accessories Documents

Features

- The fastest Micro refrigerated centrifuge
- The first micro centrifuge that can hold up to 50ml conical tubes
- Various rotors and adaptors to hold various volumes of tubes.
- Easy-Lock rotor with a set of V-rings(only for Micro rotor)
- A separate ‘PULSE’ key for quick spin
- Fast cool function
- With inverter type compressor, very quiet and high efficiency operation
- Small footprint with 380 x 654mm
- Bio-seal (Public Health England Porton Down) certified Easy-lock rotor

Technical Specifications

Max. RPM/RCF (Fixed angle)
18,000/ 30,536 x g
Max. RPM/RCF (Swing-out)
13,000/ 16,438 x g
Max. capacity (Fixed angle)
8 x c50 mL, 48 x 1.5/ 2.0 mL
Max. capacity (Swing-out)
24 x 1.5/ 2.0 mL, 4 x MTP
Temp. Range (°C)
-12 ~ 40
Fast Cool Button
Yes
Time control
Pulse, timed < 10 hr or continuous
Time counting modes
Selectable, at set speed or from starting
Noise level (dB)
< 60dB
ACC/ DEC Ramp
9/ 10
Display
White FND
Program memory
100
Parameters on display window
RPM or RCF, Time (Hr: min), Temp, ACC, DEC
Automatic rotor identification
Yes
Motorized lid open & close
Yes
Imbalance cut-off
Yes
Lid drop protection
Yes
Safety lid lock
Yes
Power requirement (KVA)
2
Power supply
AC 220-230 V, 50/60 Hz (110 V optional)
Dimension (W x D x H, mm)
380 x 654 x 312
Weight without rotor (kg)
53.5 kg
CE Mark
Yes
Cat. No.
GZ-1848R (GZ-1848R-110)

Accessories

Fixed angle rotor
GRF-M-c50-8
GRF-M-c50-8
Fixed angle rotor
GRF-M-c15-12
GRF-M-c15-12
Fixed angle rotor
GRE-M-m5.0-20
GRE-M-m5.0-20
Fixed angle rotor
GRE-M-m2.0-48
GRE-M-m2.0-48
Fixed angle rotor
GREB-M-m2.0-30
GREB-M-m2.0-30
Fixed angle rotor
GREB-M-m2.0-24
GREB-M-m2.0-24
Fixed angle rotor
GRE-M-s0.2-64
GRE-M-s0.2-64
Swing out rotor
GRD-M-m2.0-24
GRD-M-m2.0-24
Swing out rotor
GRD-M-mw-2
GRD-M-mw-2
