406 & 406(CE IVDR)
Features Technical Specifications Accessories Documents

Features

- Compact and robust small centrifuge 406 is ideal for routine low-speed centrifugation.
- Commonly used in the fractionation of blood samples and simple precipitation of biological samples
- Automatic lid release and vivid end alarm for easy retrieval of samples
- Supplied with a 6-tube capacity rotor; 12-tube capacity rotor optional on request

Technical Specifications

Max. RPM
4,000 rpm
Max. RCF
2,075 x g
Max. capacity
6 x vacuum tube, 12 x vacuum tube optional
Time control
Timed < 100 min or continuous
Automatic RPM/ RCF conversion
Yes
Program memory
30
Parameters on display window
RPM or RCF, Time (Min: Sec)
Noise level (dependent on rotor)
≤52 dB
Acc. time to max. speed
≤20 sec
Dec. time from max. speed
≤20 sec
Imbalance cut-off
Yes
Safety lid lock
Yes
Lid drop protection
Yes
Automatic lid release at completion
Yes
Dimension (W x D x H, mm)
296 x 412 x 206
Power Requirement (VA)
140
Weight without rotor (kg)
17.5
Power supply
AC 220-230 V, 50/60 Hz (110 V optional)
CE Mark
Yes
Cat. No.
GZ-0406 (GZ-0406-110)

Accessories

Fixed angle rotor
GRA-15-12
GRA-15-12
Fixed angle rotor
GRA-15-6
GRA-15-6
