GYROZEN

Features

- For up to 6,000 rpm (3,960 xg) with 6 x 50 ml conical tube fixed angle rotor
- Commonly used in the fractionation of blood samples and simple precipitation of biological samples
- Fast cooling function to 4°C for fast startup of cooled samples
- The compressor-off function when lid is open minimizes unnecessary cooling and frosting
- Intuitive control interface with numeric input buttons allows easy setting and editing of running conditions.
- Selectable time mode of “at set SPEED” for counting running time only when the set speed is reached
- A separate "PULSE" key for a quick spin
- Parameters can be changed during operation.
- Key lock function helps the set parameters secured during operation.
- With motorized lid mechanics, only a gentle touch is sufficient to close and open the lid.
- Lid drop protection design allows easiness and safety when loading or unloading samples.
- A large assortment of rotors, buckets, and adaptors for microtubes and all sizes of tubes up to 100 ml

Technical Specifications

Max. RPM/ RCF (Fixed angle): 6,000/ 3,960 x g
Max. RPM/ RCF (Swing out): 4,800/ 3,888 x g
Max. Capacity (Fixed angle): 6 x 50 ml, 24 x 15 ml
Max. Capacity (Swing out): 4 x 100 ml, 4 x 8 x vacuum tube, 4 x MTP, 2 x DWP
Temp. range (°C): -10 ~ 40
FAST cool button: Yes
Time control: Pulse, timed < 100 hr or continuous
Time counting modes: Selectable, at set speed or from starting
Automatic RPM/ RCF conversion: Yes
Noise level (dB): ~ 60
ACC/ DEC Ramps: 9/10
Program memory: 100
Parameters on display window: RPM or RCF, Operation Status, Lid Open/ Close, Time (Hr:Min), Temp, ACC/ DEC
Display: White LCD
Automatic rotor identification: Yes
Imbalance cut-off: Yes
Safety lid lock: Yes
Lid drop protection: Yes
Dimension (W x D x H, mm): 584 x 535 x 317
Power requirement (VA): 900
Weight without rotor (kg): 65
Power supply: AC 220-230 V, 50/60 Hz (110 V optional)
CE mark: Yes
Cat. No.: GZ-0624R-B (GZ-0624R-B-110)
