1248
Features
- The multi-purpose centrifuges designed for large-volume daily-working laboratories
- Max. speed of 12,000 rpm with high capacity and a large assortment of rotor
- Intuitive control interface with numeric input buttons allows easy setting and editing of running conditions.
- Selectable time mode of "at set SPEED" for counting running time only when the set speed is reached
- A separate "PULSE" key for a quick spin
- Parameters can be changed during operation.
- Key lock function helps the set parameters secured during operation.
- With motorized lid mechanics, only a gentle touch is sufficient to close and open the lid.
- Lid drop protection design allows easy and safe loading or unloading of samples.
- A large assortment of rotors, buckets, and adaptors support diverse applications with one instrument.
- Max. speed of 12,000 rpm with high capacity and a large assortment of rotor
- Intuitive control interface with numeric input buttons allows easy setting and editing of running conditions.
- Selectable time mode of "at set SPEED" for counting running time only when the set speed is reached
- A separate "PULSE" key for a quick spin
- Parameters can be changed during operation.
- Key lock function helps the set parameters secured during operation.
- With motorized lid mechanics, only a gentle touch is sufficient to close and open the lid.
- Lid drop protection design allows easy and safe loading or unloading of samples.
- A large assortment of rotors, buckets, and adaptors support diverse applications with one instrument.
Technical Specifications
- Max. RPM/RCF (Fixed angle)
- 12,000/ 16,582 x g
- Max. RPM/RCF (Swing-out)
- 5,000/ 5,394 x g
- Max. capacity (Fixed angle)
- 6 x 85 ml, 30 x 1.5/ 2.0 ml
- Max. capacity (Swing-out)
- 4 x 250 ml, 48 x 15 ml, 16 MTPs
- Time control
- Pulse, timed < 100 min or continuous
- Time counting range
- Selectable, at set speed or from starting
- RCF/RPM conversion
- Yes
- Noise level (dependent on rotor)
- ≤60 dB
- ACC/ DEC ramps
- 9/ 10
- Program memory
- 100
- Parameters on display window
- RPM or RCF, Operation Status, Lid Open/ Close, Time (Min: Sec), ACC/ DEC
- Display
- White LCD
- Automatic rotor Identification
- Yes
- Imbalance cut-off
- Yes
- Safety lid lock
- Yes
- Lid drop protection
- Yes
- Motorized lid open & close
- Yes
- Automatic lid release at completion
- Yes
- Dimension (W x D x H, mm)
- 473 x 561 x 330
- Power Requirement (VA)
- 900
- Weight without rotor (kg)
- 40
- Power supply
- 230 V, 50 Hz (AC 220-230 V, 50/60 Hz; 110 V optional)
- CE MARK
- Yes
- Cat. No.
- GZ-1248 (GZ-1248-110)
Accessories
Fixed angle rotor
GRF-G-85-6
Fixed angle rotor
GRF-G-50-8
Fixed angle rotor
GRF-G-c50-8
Fixed angle rotor
GRF-G-c15-12
Fixed angle rotor
GRA-G-15-24
Fixed angle rotor
GRF-G-m2.0-30
Swing out rotor
GRS-G-r250-4
Swing out rotor
GRS-G-250-4
Swing out rotor
GRS-G-100-6
