Features

- The multi-purpose large-capacity centrifuges designed for large-volume daily-working laboratories
- Max. speed of 15,000 rpm with high capacity and a large assortment of rotor
- Intuitive control interface with numeric input buttons allows easy setting and editing of running conditions.
- Selectable time mode of "at set SPEED" for counting running time only when the set speed is reached
- A separate "PULSE" key for a quick spin
- Parameters can be changed during operation.
- Key lock function helps the set parameters secured during operation.
- With motorized lid mechanics, only a gentle touch is sufficient to close and open the lid.
- Lid drop protection design allows easiness and safety when loading or unloading samples.
- A large assortment of rotors, buckets, and adaptors support diverse applications doable with one instrument.

Technical Specifications

Max. RPM/ RCF (Fixed angle)
15,000/ 24,249 x g
Max. RPM/ RCF (Swing-out)
5,000 rpm/ 5,394 x g
Max. capacity (Fixed angle)
6 x 85 ml, 30 x 1.5/ 2.0 ml
Max. capacity (Swing-out)
4 x 750 ml, 80 x 15 ml, 16 MTPs
Time control
Pulse, timed < 100 min or continuous
Time counting range
Selectable, at set speed or from starting
Noise level (dependent on rotor)
≤60 dB
ACC/DEC ramps
9/ 10
Program memory
100
Parameters on display window
RPM or RCF, Operation Status, Lid Open/ Close, Hr: Min, Temp, ACC. DEC. step
Display
White LCD
Automatic RPM/RCF conversion
Yes
Automatic rotor Identification
Yes
Imbalance cut-off
Yes
Safety lid lock
Yes
Lid drop protection
Yes
Motorized lid open & close
Yes
Automatic lid release at completion
Yes
Dimension (W x D x H, mm)
540 x 650 x 380
Power Requirement (kVA)
1.5
Weight without rotor (kg)
57
Power supply
AC 220-230 V, 50/60 Hz (110 V optional)
CE Mark
Yes
Cat. No.
GZ-1580 (GZ-1580-110)

Accessories

Fixed angle rotor
GRF-G-85-6
GRF-G-85-6
Fixed angle rotor
GRF-G-50-8
GRF-G-50-8
Fixed angle rotor
GRF-G-c50-8
GRF-G-c50-8
Fixed angle rotor
GRF-G-c15-12
GRF-G-c15-12
Fixed angle rotor
GRA-G-15-24
GRA-G-15-24
Fixed angle rotor
GRF-G-m2.0-30
GRF-G-m2.0-30
Swing out rotor
GRS-G-r750-4
GRS-G-r750-4
Swing out rotor
GRS-G-750-4
GRS-G-750-4
Swing out rotor
GRS-G-r250-4
GRS-G-r250-4
Swing out rotor
GRS-G-250-4
GRS-G-250-4
Swing out rotor
GRS-G-100-6
GRS-G-100-6
