1696R II

Features

- The largest swing out capacity multi-purpose centrifuge designed for daily-working laboratories
- High RPM up to 16,000 rpm (27,991 xg)
- Swing-out bucket rotors accommodate bottles up to 1,000 mL
- Motorized soft-touch lid for easy effortless closing
- Highly visible display screen with integrated touch buttons for easy maintenance
- Numeric keys for quick setting
- A separate "PULSE" key for a quick spin
- Compressor-off function when the lid is open minimizes unnecessary cooling and frosting.
- Selectable time mode of "at set SPEED" for counting running time only when the set speed is reached
- Fast-Cool function that cools the system temperature down to 4°C for a quick start
- Key-lock function to prevent any unintentional changes during operation
- Automatic rotor recognition and imbalance detection warning for safety
- A large assortment of rotors, buckets, and adaptors support diverse applications with one instrument.

Technical Specifications

Max. RPM/ RCF (Fixed angle)
16,000 / 27,991 xg
Max. RPM/ RCF (Swing out)
5,000 / 5,394 xg
Max. Capacity (Fixed angle)
6 x 250 mL
Max. Capacity (Swing out)
4 x 1,000 mL
Temp.Range (℃)
-11 ~ 40
FastCool Button
Yes
Time Control
Timed < 100 hr or Continuous
Time Count Modes
Selectable, At Set Speed Or From Starting
ACC/ DEC Ramps
9/ 10
Program Memory
100 (3 Direct Program Save/Call)
Display
White FND
Parameters on display window
RPM or RCF, Time (Hr: Min), Temp, ACC/ DEC, Program No.
Automatic RPM/ RCF Conversion
Yes
Automatic Rotor Identification
Yes
Imbalance Cut-Off
Yes
Safety Lid Lock /Lid drop protection
Yes
Motorized Lid Open & Close
Yes
Noise level (depenent on rotor)
<70 dB
Dimension (WxDxH, mm)
775 x 695 x 395
Weight without Rotor (Kg)
132
Power Requirement (kVA)
2
Power supply
AC 220~230V,60Hz; (230V, 50Hz; 110V) optional
CE Mark
NO
Cat. No.
GZ-1696RII, (GZ-1696RII-50, GZ-1696RII-110)

Accessories

Fixed angle rotor
GRF-B-250-6
GRF-B-250-6
Fixed angle rotor
GRF-B-85-6
GRF-B-85-6
Fixed angle rotor
GRF-B-50-8
GRF-B-50-8
Fixed angle rotor
GRF-B-c50-8
GRF-B-c50-8
Fixed angle rotor
GRF-B-c15-12
GRF-B-c15-12
Swing out rotor
GRF-B-m5.0-20
GRF-B-m5.0-20
Fixed angle rotor
GRF-B-m2.0-48
GRF-B-m2.0-48
Swing out rotor
GRS-B-1000-4
GRS-B-1000-4
Swing out rotor
GRS-B-750-4
GRS-B-750-4
Swing out rotor
GRS-B-r750-4
GRS-B-r750-4
Swing out rotor
GRS-B-250-4
GRS-B-250-4
Swing out rotor
GRS-B-r250-4
GRS-B-r250-4
Swing out rotor
GRS-B-100-6
GRS-B-100-6
