GYROZEN

Features

- The 1736R, High Fixed angle volume, floor-standing centrifuge
- High RPM up to 17,000 rpm (32,310 x g)
- The short working height of 84 cm (33 inches) ensures easy loading and unloading.
- With motorized lid mechanics, only a gentle touch is sufficient to close and open the lid.
- Lid drop protection design allows easiness and safety when loading or unloading samples.
- Fast system temperature cooling function to 4℃ for fast startup of cooled samples
- The compressor-off function when the lid is open minimizes unnecessary cooling and frosting.
- Intuitive control interface with numeric input buttons allows easy setting and editing of running conditions.
- Selectable time mode of "at set SPEED" for counting running time only when the set speed is reached
- A separate "PULSE" key for quick spin
- Parameters can be changed during operation.
- Key lock function helps the set parameters secured during operation.

Technical Specifications

Max. RPM/ RCF (Fixed angle): 17,000 / 32,310 x g
Max. RPM/ RCF (Swing-out): 5,000/ 5,394 x g
Max. capacity / Fixed angle: 6 x 500 ml
Max. capacity / Swing-out: 4 x 250 ml,16 MTPs
Temp range (℃): - 20 ~ 40
FAST cool button: Yes
Time control: Pulse, timed < 100 hr or continuous
Time counting range: Selectable, at set speed or from starting
Automatic RPM/RCF conversion: Yes
Noise level (dependent on rotor): ≤56 dB
ACC/ DEC ramps: 9/ 10
Program memory: 100
Parameters on display window: RPM or RCF, Operation Status, Lid Open/ Close, Time (Hr: Min), Temp, ACC/ DEC
Display: White LCD
Automatic RPM/ RCF conversion: Yes
Automatic rotor Identification: Yes
Imbalance cut-off: Yes
Safety lid lock: Yes
Lid drop protection: Yes
Motorized lid open & close: Yes
Dimension (W x D x H, mm): 473 x 600 x 840
Power Requirement (kVA): 2.5
Weight without rotor (kg): 93
Power supply: AC 220-230 V, 50/60 Hz (110 V optional)
CE MARK: Yes
Cat. No.: GZ-1736R (GZ-1736R-110)
