GYROZEN

Features

- The 2236R, a high-speed, largest fixed angle volume, floor-standing centrifuge designed for a multi-user environment
- Ideal for large-volume harvesting in cellular and molecular biology works, clinical preparations, industrial applications, etc.
- High Maximum RPM of 22,000 rpm (54,111 xg)
- Instrument lock/unlock by password control and protocol management by user ID is ideal for core lab facility or multi-user environment
- A large assortment of rotors, buckets, and adaptors support diverse applications doable with one instrument.
- Fast system cooling function to 4℃ for a fast startup of cooled samples
- The compressor-off function when the lid is open minimizes unnecessary cooling and frosting.
- With motorized lid mechanics, only a gentle touch is sufficient to close and open the lid.
- Lid drop protection design allows easiness and safety when loading or unloading samples.
- Intuitive control interface with numeric input buttons and graphic pictograms for easy setting and editing of running conditions.
- Windows CE-based 7" LCD Touch Screen with simultaneous display of all the parameters of set and actual values.
- Selectable time mode of "at set SPEED" for counting running time only when the set speed is reached
- Up to 5 protocols per run can be combined for the convenient operation of complicated experiments.
- The parameters of TIME, TEMP, ACC, and DEC are allowed to be changed during operation.

Technical Specifications

Max. RPM/RCF (Fixed angle): 22,000/ 54,111 x g
Max. RPM/RCF (Swing-out): 5,000/ 5,394 x g
Max. capacity (Fixed angle): 6 x 1,000 ml
Max. capacity (Swing-out): 4 x 250 ml, 48 x 15 ml, 16 x MTPs
Temp range (℃): - 20 ~ 40
FAST cool button: Yes
Time control: Timed < 100 hr or continuous
Time counting range: Selectable, at set speed or from starting
Noise level (dependent on rotor): ≤56 dB
ACC/ DEC ramps: 9/ 10
Program memory: 100
Parameters on display window: Simultaneous display of all parameters of set and actual figures
Display: 7" LCD Touch Screen
Automatic RPM/ RCF conversion: Yes
Automatic rotor Identification: Yes
Imbalance cut-off: Yes
Safety lid lock: Yes
Lid drop protection: Yes
Motorized lid open & close: Yes
Power Requirement (kVA): 4
Dimension (W x D x H, mm): 824 x 634 x 1,049
Weight without rotor (kg): 240
Power supply: AC 220~230V 60Hz (230V, 50Hz; 110 V optional)
CE Mark: Yes
Cat. No.: GZ-2236R (GZ-2236R-50, GZ-2236R-110)
