HyperCool 3055
Features
• Effective for fast freeze drying of any samples
• HyperVAC-MAX empowered by HyperCOOL guarantees capacity and performance at higher level.
• HyperCOOL by itself, when equipped with manifolds or chambers, becomes a versatile freeze dryer.
• Extended applications for concentrating wider range or larger volume of solvents.
• The compatible vacuum rotary vane pump generates vacuum down inside the chamber.
• Up to 8 external bottles can be accommodated by the manifolds of HyperCOOL.
• HyperVAC-MAX empowered by HyperCOOL guarantees capacity and performance at higher level.
• HyperCOOL by itself, when equipped with manifolds or chambers, becomes a versatile freeze dryer.
• Extended applications for concentrating wider range or larger volume of solvents.
• The compatible vacuum rotary vane pump generates vacuum down inside the chamber.
• Up to 8 external bottles can be accommodated by the manifolds of HyperCOOL.
Technical Specifications
- Ultimate chamber temp (at RT) (℃)
- -55
- Chamber volume (L)
- 4
- Trap (Chamber) size (Ø x L)
- 165 x 202
- ICE Condensing capacity (kg)
- 3
- ICE Condensing performance (kg/day)
- 2.5
- Compressor
- 1/2 HP
- Refrigerant
- R507
- Digital readout
- Time, Temperature, Vacuum
- Function
- Keylock, Defrost
- Power requirement (Resting, VA)
- 642
- Power supply(V/Hz)
- 230 V, 50 Hz (AC 220-230 V, 50/60 Hz; 110 V optional)
- Dimension (W x D x H, mm)
- 400 x 660 x 570
- Weight (kg)
- 58
- Cat. No
- Hyper-HC3055 (Hyper-HC3055-110)
